TrueTone 1Spot Pro CS6 Low-Profile 6-output Isolated Power Supply

TrueTone 1Spot Pro CS6 Low-Profile 6-output Isolated Power Supply

Truetone presents the most powerful slim line power supply in its class, the 1 SPOT Pro CS6. Utilizing the energy efficient technology found in all 1 SPOT’s, the CS6 is the first low-profile power brick to be able to put out up to 1600mA of pure, silent power.

Just like its bigger brothers in the 1 SPOT Pro line, the CS6 has a variety of DC voltages available to power just about any pedal on the market. Each output is completely isolated, regulated and filtered, eliminating crosstalk and noise. With no big transformer to hinder their performance, proximity noise is no longer an issue with any 1 SPOT Pro.

The low-profile design of the 1 SPOT Pro CS6 allows it to be mounted under flat pedalboards like the Pedaltrain® Nano and Metro series. However, the compact design is also perfect for mounting on top of pedalboards, serving the dual role of power supply and pedal riser.

Specifications

• Type:Pedalboard Power Supply
• Inputs:120V AC
• Outputs:2 x 9V DC 500mA, 2 x 9V/12V 200ma, 2 x 9V/18V 100mA
• Maximum Output Current:1.6A
• Isolated Output:Yes
• Features:Switched-mode power supply
• Height:1.22"
• Width:6.3"
• Depth:3.46"
• Weight:1.3 lbs.
• Manufacturer Part Number:CS6
